GRF-1300A User Manual and Teaching Materials
4. A connection diagram is shown below.
5. A blue tooth device or wireless network card can also be used
in the same way to create a signal to measure.
Experiment
results
Transmitting frequency: _____
Transmitted signal power: _____
Question What are the advantages for a wireless mouse to operate in the
2.4 G bandwidth?
Caution Use the Peak Hold function on the spectrum analyzer to capture
the signal emitted from the wireless mouse. It is not easy to
dynamically measure the signal.
90
