GSP-810 User Manual
29
DISPLAY SYSTEM
Display Device CRT Display, 8 x 10 graticule, 6-inch waveform screen
LCD Display, 4 line x 20 character data screen
Display Function Center Frequency Control, Bandwidth, Reference Level, Span
Range, Amplitude
FUNCTIONS
Marker Mode Absolute, relative, PK->marker, marker->center
Number of Markers 2
Marker Resolution 0.1dB, 1 kHz
Marker Accuracy 0.1dB
± amplitude accuracy
Memory 10 memorise of save / recall
Trace Max. hold, average (2 ~ 32 traces), freeze (Hold)
Setup Access parameters
Demodulator WB FM, 120kHz deviation
MB FM, 75kHz deviation
NB FM, 30kHz deviation
AM
Outputs : Internal speaker, 3.5mm stereo jack, wired for mono
operation
Calibrate Signal 80MHz, -30dBm
INTERFACE
RS-232C standard & remote display software
(The software will be downloaded from GW Web-Site.)
POWER SOURCE
AC 100V/120V/220V/230V
±10%, 50/60Hz
DIMENSIONS & WEIGHT
310(W) x 150(H) x 455(D)mm, Approx. 8.5kg
