GSP-810 User Manual
12
Field Selection Key Data Entry
Resolution Bandwidth RBW SPINNER to scroll
(SPAN OF
0 Hz / div ONLY)
Demodulation (Optional
Receiver)
SHIFT , DEMOD SPINNER to select demod type
Power Meter (Optional) SHIFT , PWR MTR SPINNER selects change line;
Í or Î to select an item; SPINNER
to scroll
Tracking Generator
(Optional)
SHIFT , TRK GEN SPINNER selects change line;
Í or Î to select an item; SPINNER
to scroll
Marker to Peak SHIFT , PK ÎMKR No data to enter
Marker to Center
Frequency
SHIFT , MKR
ÎCF No data to enter
Trace Functions SHIFT , TRACE SPINNER select trace item;
Í or Î
change value or turn function ON /
OFF
Setup Functions SHIFT , SETUP SPINNER select setup item;
Í or Î
change value or turn function ON /
OFF
Table 1 - Data field selection and entry.
