5. LO2 Status
This displays the status of LO2. An internal status is monitored to determine
if it is “Locked” or “Unlocked” with the result being displayed.
6. LO3 Status
This displays the status of LO3. An internal status is monitored to determine
if it is “Locked” or “Unlocked” with the result being displayed.
7. POWER Units
This controls the units displayed for the optional power meter. The
selections are “mW” and “dBm”.
8. Marker Style
The Marker can appear as type of either “Line” or “Dot”. By pushing the
“
Î ” key can toggle the option
SAVING POWER-UP SYSTEM PARAMETERS
Power-up information will be saved any time the setup screen is exited. To access
the setup screen, press the SHIFT SETUP key. To exit the setup screen, press the
ENTER key. When exiting, the fields will be saved to a non-volatile storage device.
The information saved includes the Center Frequency, Span, and Reference Level
fields, the marker frequencies, the power meter fields, and the Tracking Generator
fields.
