GSP-810 User Manual
28
6.0 Specifications
Specifications are subject to change without notice. Refer to Goodwill
Instrument Co., LTD. for latest specifications.
SPECIFICATIONS
FREQUENCY
Frequency Range 150kHz ~ 1GMHz
Aging Rate
±10ppm, 0 ~ 50ºC, ±2ppm/yr
Span Range Zero, 2kHz ~ 100MHz/div in 1-2-5 sequence
Phase Noise -77dBc/Hz @ 1GHz 30kHz offset
Frequency Resolution 1kHz C.F. entry, 40Hz sweep resolution at 2kHz/div
Frequency Display 6 1/2 digit setting
Frequency Control Digital phase locked
RESOLUTION BANDWIDTH
RBW Range 3kHz, 30kHz, 220kHz, 4 MHz
RBW Accuracy 15%
Video Bandwidth Range 1.6kHz / 90kHz couple with RBW
AMPLITUDE
Measurement Range -100dBm ~ +20dBm
Overload Protection +30dBm continuous,
±25VDC
Reference Level Range -30dBm ~ +20dBm
Amplitude Display Range 75dB
Amplitude Accuracy
± 1.5dB typical @ 0dBm, 80MHz
Frequency Flatness
± 1.5dB over 100MHz, ± 2.5dB typical over entire band /
± 3dB : 150kHz~10MHz
Amplitude Level Linearity
± 1.5dB over 70dB
DYNAMIC RANCE
Average Noise Floor -95dBm @30kHz RBW, -100dBm typical /
-75dBm : 150kHz ~ 10MHz
Third Inter-Modulation <-70dBc, @-40dBm input, 2tones, 2MHz apart /
<-45dBc:150kHz ~ 10MHz
Harmonic Distortion <-40dBc, RF input < selected reference
Non-Harmonic Spurious <-60dBc typical down from reference level, average, 5MHz/div
