Using the Oscilloscope
15
U
SING THE
O
SCILLOSCOPE
This chapter describes the oscilloscope
functionalities in the GDS‐122: setting it up and
measuring simple waveforms, using advanced
measurement functions, and configuring the
system settings. The menu tree section at the end
gives you an overview of all functionalities and a
quick access to each of them. For the multimeter
functionalities, see page
107H
83.
Basic Operations......................................................
108H
16
Configurations ........................................................
109H
22
Measurements .........................................................
110H
39
Advanced Viewings ..................................................
111H
45
Calibration ..............................................................
112H
51
Saving/Recalling Waves and Settings .........................
113H
53
Menu Tree / Operation Shortcuts ..............................
114H
56
Using the Software...................................................
115H
61
GDS-122 User Manual
16
4B
Basic Operations
Operation flow The Basic Operations section describes how to set
up the GDS‐122 and observe an input signal, step‐
by‐step.
1. Powering up the GDS‐122
2. Connecting an input signal
3. Using the Autoset / Introducting the display
4. Adjusting the scales
5. Adjusting the waveform position
Advanced
operations
For more advanced or detailed operations, see the
following chapters.
• Configurations (page
116H
22)
• Measurements (page
117H
39)
• Advanced Viewings (page
118H
45)
• Calibrations (page
119H
51)
19B
1. Powering up the GDS-122
1. Pressing the
power switch
Press the power switch. The welcome
screen with the corporate logo
appears on the display.
Press any key to continue.
To adjust the display brightness, press
the switch on the side. The backlight
turns on and off.
2. Activating the
oscilloscope
Press any key (for example the MENU
key) to enter the oscilloscope mode.
See the battery level icon at the top left
corner of the display and connect the (Example)
MENU
