APPENDIX
39
Horizontal Axis Sweep time
accuracy
0.2µS to 0.5S/DIV, ±3%
x10MAG accuracy ± 5% (20/50nS uncalibrated)
Linearity ± 3%, x10:±5% (20/50nS uncalibrated)
X-Y Mode Sensitivity Same as vertical axis
Bandwidth DC to at least 500kHz
Phase Difference ≤ 3 degrees at DC to 50kHz
Z-Axis Sensitivity 5Vpp (Positive going reduces intensity)
Bandwidth DC to 2MHz
Input resistance Approx. 47kΩ
Max input voltage CAT II 30Vpeak (AC ≤1kHz)
Waveform Positive-going square wave
Frequency Approx. 1 kHz
Duty Ratio Within 48:52
Output voltage 2 Vp-p ±2%.
Probe
Compensation
Signal
Output impedance Approx. 1 kΩ
Display Digits Maximum 5 digit decimal Frequency
Counter
Frequency Range 50Hz to 30MHz
Accuracy 50Hz to 1kHz: ±0.05%
1kHz to 30MHz: ±0.02%
Sensitivity > 2DIV
LCD Display VOLT/DIV, TIME/DIV, X-Y, Frequency
Backlight Orange
CRT Type 6-inch rectangular, internal graticule
Phosphor P 31
Acceleration Volt. Approx. 2kV
Screen Size 8 × 10 DIV (1 DIV = 10mm (0.39in))
Power Source AC115V/230V±15%, 50/60Hz
Power Approx. 40VA, 35W(max.)
Operation
Environment Indoor use, Altitude ≤ 2000 m
Ambient temperature :
To satisfy specifications:10℃ to 35℃ (50°F to 95°F)
Maximum operating range: 0℃ to 40℃ (32°F to 104°F)
Relative humidity: 85% RH(max.) non-condensing
Installation Category II, Pollution degree 2
Storage
Environment Ambient temperature: -10℃ to 70℃
Relative humidity: 70%RH (maximum)
Accessories Power cord x 1, User manual x 1, Probe x 2
Dimensions 310 (W) x 150 (H) x 455 (D) mm
Weight Approx.8.2kgs (18.0lbs)
GOS-630FC User Manual
40
Declaration of Conformity
We
GOOD WILL INSTRUMENT CO., LTD.
(1) No.7-1, Jhongsing Rd., Tucheng City, Taipei County, Taiwan
(2) No. 69, Lu San Road, Suzhou City (Xin Qu), Jiangsu Sheng, China
declare, that the below mentioned product
Type of Product: Oscilloscope
Model Number: GOS-630FC
are herewith confirmed to comply with the requirements set out in the
Council Directive on the Approximation of the Law of Member States
relating to Electromagnetic Compatibility (2004/108/EC, 92/31/EEC,
93/68/EEC) and Low Voltage Directive (2006/95/EC).
For the evaluation regarding the Electromagnetic Compatibility and
Low Voltage Directive, the following standards were applied:
◎
EMC
EN 61326-1: Electrical equipment for measurement, control and laboratory
use –– EMC requirements (2006)
Conducted Emission
Radiated Emission
EN 55011: 1998 + A1:1999 +
A2:2002, ClassB
Electrical Fast Transients
EN 61000-4-4: 2004
Current Harmonics
EN 61000-3-2: 2000 + A2:2005 Surge Immunity
EN 61000-4-5: 1995 + A1:2001
Voltage Fluctuations
EN 61000-3-3: 1995 + A1: 2001
+A2: 2005 Conducted Susceptibility
EN 61000-4-6: 1996 + A1:2001
Electrostatic Discharge
EN 61000-4-2: 1995 + A1:1998 +
A2:2001 Power Frequency Magnetic Field
EN 61000-4-8: 1993 + A1:2001
Radiated Immunity
EN 61000-4-3: 2002 + A1:2002 Voltage Dip/ Interruption
EN 61000-4-11: 2004
◎ Safety
Low Voltage Equipment Directive 2006/95/EC
Safety Requirements
IEC/EN 61010-1: 2001
