GW Instek GOS-630FC User Manual
Page 2
TABLE
OF
CONTENTS
3
Table of Contents
S
AFETY INSTRUCTIONS ................................................... 5
P
RODUCT OVERVIEW ..................................................... 10
Product Description ............................. 10
Main Features ...................................... 11
Block Diagram ..................................... 12
P
ANEL OVERVIEW .......................................................... 13
Front Panel Overview ........................... 13
Display Controls .................................. 14
LCD Display ......................................... 15
Horizontal Controls ............................. 16
Vertical Controls .................................. 17
Trigger Controls ................................... 19
Input Terminals.................................... 22
Rear Panel Overview ............................ 23
S
ETUP............................................................................. 24
Default Settings ................................... 24
Set up & Probe Compensation ............. 26
M
EASUREMENT.............................................................. 28
Single Channel (Basic) Measurement .. 28
Dual Channel Measurement................. 29
Waveform Addition/Subtraction ........... 31
Frequency Measurement ...................... 31
X-Y Mode ............................................. 32
Waveform Magnification ...................... 33
F
AQ ................................................................................ 34
GOS-630FC
User
Manual
A
PPENDIX ...................................................................... 36
Line Voltage & Fuse Replacement ........ 36
Specifications ...................................... 38
Declaration of Conformity .................... 40
