Model X40 Instruction Manual Rev. 3.3 Page 49 of 64
Reading Register
Current gas reading of the channel assigned to the register.
Status Register
Bit 0 Alarm 1 0 = No Alarm 1 = In alarm 1
Bit 1 Alarm 2 0 = No Alarm 1 = In alarm 2
Bit 2 Alarm 3 0 = No Alarm 1 = In alarm 3
Bit 3 Fault 0 = No Fault 1 = Sensor/Alarm Fault
Bit 4 1 Cal 0 = Normal Operation 1 = In Cal
Bit 5 Comm Error 0 = Normal Operation 1 = Communication Error
Bit 6 &
Bit7 1
Decimal Point
00 = No Decimal Point(No Divisor)
10 = 2 Decimal Point (Divisor of
100)
01 = 1 Decimal Point ( Divisor of 10)
11 = Undefined (Default to No
Decimal Point)
Bit 8 Smart Battery Pack 0 = No Smart Battery Pack 1 = Smart Battery Pack
Bit 9 Battery Error 0 = No Battery Error 1 = Battery Error
Bit 10 Low Battery 0 = No Low Battery 1 = Low Battery
Bit 11 Not Used
Bit 12
Wireless Network
Type 0 = 320 1 = 300
Bits
13-15
Type
000 = Channel Disabled 100 = Repeater 5
001 = CXT Sensor 101 = Sensor
010 = Alarm Station 110 = Undefined (Sensor)
011 = SmartHMI 5 111 = Undefined (Sensor)
1 These bits are only active for sensor devices
