Model X40
Model X40 Instruction Manual Rev. 3.3 Page 25 of 64
Pole
U-bolts U-bolts
Figure 23 Typical NEMA7 with Transceiver
Table 1 X40 Model 100 Terminal Board Connector Plugs
J1 4-Pin Connector Modbus ™ Out (Wireless Transceiver Option)
J2 6-Pin Header Wireless Transceiver Programming Header
J3 6-Beau Connector Battery operation or display interface dependent on sensor configuration
J4 4-Pin Connector Modbus ™ In – Connects to X40
J5 Not used
J6 Not used
J7 4-Pin Connector Connection to solar panel
J8 6-Pin Connector Wireless Transceiver
J9 5-Pin Header Terminal Board Programming
J6
J7
J4
J1
J5
J8
L9
J2
AI
N
1
W
/B
K
W
/B
N
W
/B
U
W
/G
N
W
/V
WIRELESS
A
IN
2
M
A
G
N
D
P
W
R
POWER IN
( SOLAR)
WIRELESS
PROGRAM
B A
G
N
D
24
V
MODBUS OUT
( WIRELESS)
24
V
G
N
D A B
MODBUS IN
24
V
G
N
D A B
SENSOR
P
W
R
G
N
D
SC
L
S
D
A
SP
1
S
P2
DISPLAY
JP1
SW2
SW1
TERM
PROGRAM
Figure 24 Model 100 Terminal Board
