Model X40
Model X40 Instruction Manual Rev. 3.3 Page 41 of 64
5.0 System Configuration
5.1 X40 Controller Setup
1. The PROG switch is used to enter the menu mode of the unit by swiping a programming magnet
over the corresponding marker (
). Upon entering the menus, all Modbus™ polling stops, sensor
values are not read and alarm outputs are not updated.
NOTE
If the X40 is in alarm when the user enters the menu, it will stay in alarm until they exit the
menu.
2. Upon entering the MAIN MENU, the LCD will display the following:
MAIN MENU
AUTO CONFIGURE SYSTEM
3. Use the down arrow "" switch to move to the next menu item or use the up arrow "" switch to
move to the previous menu item by swiping the programming magnet over the corresponding
markers. Swiping the PROG switch again will return the unit to normal operation.
4. Swipe the ENTER marker when the appropriate menu item is located to enter the menu.
5.2 Menu Functions
The Main Menu and consists of seven menu items:
1. Auto Configure System
2. Setup Channel Data
3. Set Channel Alarms
4. Set Relay Function
5. Inhibit & Alarm Test Mode
6. System Diagnostics
7. Time and Date
8. View TWA & Peak
5.2.1 Auto Configure System
1. Ensure that the addresses on all modules and sensors are correctly set (Section 3.0).
2. Verify that all 4-20mA inputs are turned on. (Note: Only currents above 1.8mA will be detected.)
3. Upon entering Auto Configure menu, the LCD will display:
CONFIGURATION SUMMARY
CHANNELS:## AO4S:## WIRELESS TRANSCEIVER WTS:##
RL4/ALARM STATION COUNT:##
[RUN SYSTEM AUTO CONFIGURE]
