Model X40
Model X40 Instruction Manual Rev. 3.3 Page 42 of 64
4. Swipe the ENTER marker to initiate the search. The X40 controller will perform an incremental
search for available 700/100 and 600 serial sensors starting with Modbus™ address 01h and analog
inputs with a minimum current of 1.80mA.
NOTE All sensors and modules must be powered on to be detected correctly.
NOTE
The channel tags for the analog inputs will be set to "PPM H2S" by default. These can be
changed in the Utilities menu.
NOTE
The channel tags for detected serial sensors will be set to gas type and units of the sensor
detected by default. These can be changed through the Utilities menu.
NOTE
A swipe of the PROG marker while in search mode will abort the search and restore the
previous configuration. Any devices found up to that point will not be saved.
5. The search will continue until Modbus™ address 7Fh is reached or the search is terminated by
swiping the ‘ENTER’ marker which will save the current found configuration. When all of the
connected sensors are identified, swipe ‘ENTER’ to begin detecting RL4 modules beginning with
Modbus™ address 80h.
NOTE
Once all of the attached sensors are identified, swipe the ENTER marker to move on to the
next stage (RL4 search). Each address that is not responding will take an additional two
seconds to time out.
6. The search will continue until Modbus™ address 8Fh is reached or the search is terminated by
swiping the ‘ENTER’ marker which will save the RL4 modules. When all of the connected RL4s
are identified, swipe ‘ENTER’ to begin detecting AO-4s with Modbus™ address A1h.
7. The search will continue until Modbus™ address A8h is reached or the search is terminated by
swiping the ENTER marker which will save the AO-4 modules. When all of the connected AO-4s
are identified, swipe ‘ENTER’ to begin detecting wireless radio modules starting with Modbus™
address 01h.
8. The search will continue until Modbus™ address 7Fh is reached or the search is terminated by
swiping the ENTER marker which will save the wireless radio modules found.
NOTE
A swipe of the PROG marker while in search mode will abort the search and restore the
previous configuration. Any devices found up to that point will not be saved.
5.2.2 Setup Channel Data
1. Upon entering this menu, the LCD will display:
CHANNEL 1 DATA: DECIMAL POINT:
SLAVE ID: RANGE:
DEVICE TYPE: TYPE:
ANALOG INPUT: RL4 BANK CNT:
2. A flashing cursor will appear on SLAVE ID. Swiping the magnet over:
 The markers of the up or down arrows will move the flashing cursor to the desired function.
 The ENTER marker will select the function indicated by the flashing cursor
 The markers of the up or down arrows will change the value.
