Detcon 1000_H2S User Manual
Detcon model 1000, Operator’s installation and instruction manual, S process analyzer - electrochemical sensor
Detcon Model 1000
H
2
S Process Analyzer - Electrochemical Sensor
INLET
SAMPLE
10 PSIG (CONSTANT)
SAMPLE PRESSURE
INLET
AIR
AIR
INLET
SAMPLE
OUTLET
SAMPLE
SAMPLE
FLOW
AIR
FLOW
MODEL NO.
SERIAL NO.
INPUT VOLTAGE
FREQUENCY
CURRENT LOAD
AREA CLASSIFICATION
detcon inc.
320 0 A-1 Rese arch Fo rest Dr.
Th e Wo odlan ds, TX 773 81
www.d etcon.com
PART NO.
Operator’s Installation and Instruction Manual
Detcon Model 1000 Series H
2
S Analyzer consists of two major assemblies:
1. The Model 1000 Series gas sample-conditioning assembly.
2. The Model DM-624 H
2
S gas sensor (using Alcohol Free - Electrochemical Sensor or
Hi-Range Electrochemical Sensor)
DETCON, Inc.
4055 Technology Forest Blvd.,
The Woodlands, Texas 77381
Ph.281.367.4100 / Fax 281.298.2868
www.detcon.com
June 6, 2012• Document #2945• Revision 2.8
