Figure 19 N7 Controller PCA
CAUTION
The cable used to connect to the terminals of the X40-32-N7 must be rated for a
minimum of 105ºC.
4. If the unit comes with the optional mounting plate and a Condulet, attach the mounting plate
assembly to a pole with two U-Bolts secured through the
7
/
16
" rectangle holes of the mounting plate
base (Figure 20).
J-Box w/ Transient
Protection Module
Pole
U-bolt
Figure 20 N7 Controller Assembly w/Mounting Plate
NOTE
It is highly recommended to install the cable inside rigid metal conduit to eliminate
potential EMI and RFI interference and to maintain a Class I Division I rating.
NOTE
A 6-32 or 8-32 threaded exterior ground point is provided on most junction boxes for an
external ground. If the transceiver assembly is not mechanically grounded, an external
ground strap must be used to ensure that the transceiver is electrically grounded.
