For each layer () present in the project
MobileMapper Office has created two extra layers:

–

(Final): This layer is viewed by default. It
shows all the features of the

layer,

namely those that have just been post-processed, for
which you can now see the refined positions on the
map screen, and also those not impacted by the post-
processing, whose positions are unchanged compared
to what they are in the initial

layer.

–

(Post-processed): This layer is not viewed
by default. It only contains the features that were
actually post-processed. You may choose to only view
this layer if you wish to focus on the sole post-
processed features.

(The “initial” layer is also hidden by
default.You may want to view this layer to see all the
features as they were before the post-processing step.)

MobileMapper Office has also added two different vector
layers to the project. Each vector describes the conditions
in which the baseline between each post-processed point
and the base station used has been determined. The
resulting components of the vector are also provided. The
two vector layers are:

•

Vectors (QC Passed) (in green): The vectors pertaining to
that layer meet all the quality control parameters
defined on the

Options tab (see Quality Control in Post-

Processing on page 50).

•

Vectors (QC Failed) (in red): None of the vectors
pertaining to that layer meets the quality control
parameters defined on the

Options tab. If the layer is

empty (no red vectors), then that means all the points
were post-processed successfully.
