CHAPTER
4
Manual No. 016-3001-003 61
Chapter 4
Navigating the
Viper Pro Interface
The purpose of this chapter is to familiarize the operator with the Viper Pro interface and display features. The
Viper Pro interface allows the operator to quickly view or modify settings and options, retrieve job information,
or access job features, all while navigating through the field.
Main Screen Features
The Viper Pro’s main screen offers an overview for many features and applications of the Viper Pro
system.This section is an introduction to the following features displayed on the main screen:
• Profile
• Sections
• Current Heading
• Pressure
• Speed
• Fan RPM
• Map Area
• Application Rates
• Tabs
• GPS Status Indicator
• SmarTrax Status Indicator
• Product Control Status
• Blockage Status
• Display Data
• Wireless Communication Status
