Viper Pro Guidance
8
A-B Lines
The straight A-B and fixed contour guidance patterns allow the operator to set a swath guidance based upon
the first pass driven. This A-B line can be saved for later use.
Note:
You can save multiple A-B lines per field. You need to give each line a unique name to distinguish
it from the other A-B lines saved.
Saving an A-B Line
A set A-B line may be saved for future jobs using the Straight A-B or Fixed Contour patterns.Once the job is
started:
1.
Set the A and B points for the first swath of the selected guidance pattern.
Zoom Out: Allows you to zoom out from the field or area by
touching the icon.
Zoom In: Allows you to zoom in on the field or area by touching
the icon.
LB Increase Brightness: Allows you to increase the brightness
level of an external lightbar.
LB Decrease Brightness: Allows you to decrease the
brightness level of an external lightbar.
Bird's Eye View: Allows you to switch to a 'Bird's Eve View' of
the vehicle and the field pattern.
Down Field View: Allows you to switch to a 'Down Field View'
of the vehicle and the field pattern.
Icon Name
Description
