APPENDIX
A
Manual No. 016-3001-003 197
Appendix A
System Diagrams
The following diagrams may be helpful for installing or troubleshooting the Viper Pro console or Product
Control system. The following diagrams may show optional features or components not required for operation
and will not apply to your system if the required hardware has not been installed.
Contact your local dealer for purchasing or more information on components shown in the following diagrams.
Additional system diagrams are available (free of charge) from the Raven Industries web site:
http://www.ravenprecision.com/Support/ApplicationDrawings/index2.jsp
Viper Pro with External Lightbar
Connect the lightbar to the COM3 port on the Viper Pro Auxiliary Interface cable. Refer to the following figure
and follow the lightbar installation instructions.
