System FRU weights (Continued)
TABLE 19
FRU
Weight
FC8-48E port blade
3.3 kg (7.3 lb) without media
FC8-64 port blade
3.36 kg (7.4 lb) without media
FC16-32 port blade
2.8 kg (6.2 lb) without media
FC16-48 port blade
3.3 kg (7.3 lb) without media
FC16-64 port blade
3.56 kg (7.85 lb) without media
FS8-18 encryption blade
5.5 kg (12.0 lb) without media
FX8-24 extension blade
4.2 kg (9.2 lb) without media
Port card filler panel
1.5 kg (3.2 lb)
Power supply
2.45 kg (5.4 lb)
Blower assembly
5.73 kg (12.6 lb)
WWN bezel
0.3 kg (0.6 lb)
Cable management device
0.45 kg (1.0 lb)
Chassis door
2.09 kg (4.6 lb)
Facility requirements
The facility where the Brocade DCX 8510-4 is in use must meet the following requirements to provide
for correct operation:
• Adequate supply circuit, line fusing, and wire size, as specified by the electrical rating on the chassis
nameplate.
• The environmental specifications listed in
on page 116.
• The power specifications listed in
Furthermore, if the Brocade DCX 8510-4 will be installed in an EIA rack, ensure the following:
• All equipment installed in the rack has a reliable branch circuit ground connection, and does not rely
on a connection to a branch circuit, such as a power strip.
• The rack is balanced and mechanically secured to provide stability in the event of an earthquake.
• Additional equipment does not exceed the rack’s weight limits.
