Viewing time left for auto rekey
2
Viewing time left for auto rekey
You can view the time remaining until auto rekey is no longer active for a disk LUN. The information
is expressed as the difference between the next rekey date and the current date and time, and is
measured in days, hours, and minutes.
Although you cannot make changes directly to the table, you can modify the time left using CLI. For
more information, refer to
Chapter 3, “Configuring Encryption Using the CLI” .
To view the time left for auto rekey, follow these steps:
1. Select Configure > Encryption from the menu task bar to display the Encryption Center
dialog box. (Refer to Figure 6 on page 14.)
2. Select a group, switch, or engine from the Encryption Center Devices table for which to view the
auto rekey information, then select Group/Switch/Engine > Targets from the menu task bar.
NOTE
You can also select a group, switch, or engine from the Encryption Center Devices table, then
click the Targets icon.
The Encryption Targets dialog box displays. (Refer to Figure 45 on page 62.)
3. Select a target disk device from the table, then click LUNs.
The Encryption Target Disk LUNs dialog box displays. The time left for auto rekey information is
listed in the table. (Refer to
Figure 71 ).
FIGURE 71 Time left for auto rekey
Viewing and editing switch encryption properties
To view switch encryption properties, complete the following steps:
1. Select Configure > Encryption from the menu task bar to display the Encryption Center
dialog box. (Refer to Figure 6 on page 14.)
2. Select a switch or encryption engine from the Encryption Center Devices table, then select
Switch/Engine > Properties from the menu task bar, or right-click a switch or encryption engine
and select Properties.
