Fabric OS Encryption Administrator’s Guide (LKM/SSKM) 87
53-1002925-01
Rekeying all disk LUNs manually
2
FIGURE 66 Universal IDs dialog box
4. Click Close.
NOTE
You will need to export the decommissioned key ID to the key vault.
Rekeying all disk LUNs manually
Brocade Network Advisor allows you to perform a manual rekey operation on all encrypted primary
disk LUNs and all non-replicated disk LUNs hosted on the encryption node that are in the read-write
state.
Manual rekeying of all LUNs might take an extended period of time. Brocade Network Advisor
allows manual rekey of no more than 10 LUNs concurrently. If the node has more than 10 LUNs,
additional LUN rekey operations will remain in the pending state until others have finished.
The following conditions must be satisfied for the manual rekey operation to run successfully:
• The node on which you perform the manual rekey operation must be a member of an
encryption group, and that encryption group must have a key vault configured.
• The node must be running Fabric OS 7.0.0 or later.
• The encryption group must be in the converged state.
• The target container that hosts the LUN must be online.
In addition to providing the ability to launch manual rekey operations, Brocade Network Advisor
also enables you to monitor their progress.
Setting disk LUN Re-key All
To rekey all disk LUNs on an encryption node, complete these steps:
1. Select Configure > Encryption from the menu task bar to display the Encryption Center
dialog box. (Refer to Figure 6 on page 14.)
2. Select the switch on which to perform a manual rekey from the Encryption Center Devices
table, then select Switch > Re-Key All from the menu task bar. (Refer to Figure 67 .)
