Brocade TurboIron 24X Series Hardware Installation Guide 5
53-1002981-01
Hardware features
1
• If the LED is on, the port is connected. If the LED is off, no connection exists, or the link is down
• If the LED is on or blinking, traffic is being transmitted and received on the port
LEDs for network interfaces and power supplies
The fiber and copper ports on TurboIron 24X provide status information through the LEDs listed in
Table 2 . The LEDs for network interfaces and power supplies are:
• 24 10-Gbps fiber ports (1~24 port) have LEDs located under each of them.
• Four 10/100/1000 copper ports (25~28) have Link and Activity LEDs to indicate port status.
• The Management port has a Link LED and Activity LED to indicate port status. The Link LED is
on the left of the copper connector and the Activity LED is on the right.
• The System power on LED is on the left side of the front panel.
• The dual power supply 1 and 2 LEDs are on the front panel of the power supply (when you are
facing the rear of the device).
TABLE 2 LEDs
LEDs Position State Meaning
10Gbps Port LEDs
LNK or ACT Located under the 10-GbE
ports On The port is connected.
Off No fiber port connection exists or the
link is down.
Blinking Traffic is begin transmitted or
received on the fiber port.
10/100/1000 Copper Port LEDs
Lnk This is the left LED on RJ45 On The port is connected.
Off No copper port connection exists or
the link is down.
Act This is the right LED on RJ45 On or Blinking Traffic is being transmitted or
received on the copper port.
Off No traffic is being transmitted or
received on the fiber port.
Management Port LEDs
Lnk This is the left LED on RJ45 On The port is connected.
Off No copper port connection exists or
the link is down.
Act This is the right LED on RJ45 On or Blinking Traffic is being transmitted or
received on the copper port.
Off No traffic is being transmitted or
received on the fiber port.
System Power and Power Supply LEDs
