<13. General Specifications>
13-5
IM 01S01C01-01EN
13.6 Dimensions
Electrical connection for code 5, 9, A and D
54
(2.13)
6
(0.24) 12
(0.47)
2-inch pipe
(O.D. 60.5 mm)
Mounting bracket
(optional)
126 (4.96)
139 (5.47)
159 (6.26)
Conduit connection
Conduit connection
95 (3.74)
60
(2.36)
50
(1.97)
Scroll knob
188 (7.40)
110 (4.33)
12
(0.47)
39
(1.54)
129 (5.08)
110 (4.33)
Ш70 (2.76)
Ш78 (3.07)
F1302.ai
Unit: mm (approx.inch)
Ground
terminal
Body
● Terminal Configuration ● Terminal Wiring
+
–
SUPPLY +
SUPPLY –
Communication terminals
connection hook
Power supply and output terminal
Ground terminal
SUPPLY
F1303.ai
Tag Number
(Tag plate)
As specified in order
Software Tag
(PD_TAG)
'UI1001' unless otherwise both Tag
Number
and software Tag specified in order
Node Address '0xF5' unless otherwise specified in
order
Operation
Functional
Class
BASIC or as specified
