<12. Parameter Lists>
12-5
IM 01S01C01-01EN
Relative
Index Index
Parameter Name Factory Default Write
Mode
Explanation
5 2005 MODE_BLK AUTO AUTO A universal parameter that represents block operating condi-
tion. It comprises the Actual, Target, Permit and Normal
modes.
6 2006 BLOCK_ERR - AUTO Indicates error status of the PID block. The FVX110 trans-
ducer block handles the following factors.
Bit 0 = An XD_ERROR has occurred
Bit 15 = Target mode is O/S
7 2007 UPDATE_EVT - AUTO Indicates event information if an event update occurs.
8 2008 BLOCK_ALM - AUTO Indicates error information if an error occurs in a block.
9 2009 TRANSDUCER_DIRECTORY - AUTO Parameter for storing indexes of FVX110 transducers.
10 2010 TRANSDUCER_TYPE 65535 AUTO Indicates FVX110 types.
Indicates 65535 (other) for the FVX110.
11 2011 XD_ERROR 0 AUTO Stores the most serious errors that occur in the transducer
block.
0 = No error
50 = Reset performed
100 = LCD error
12 2012 COLLECTION_DIRECTORY AUTO Stores the DD item ID for the first index of important param-
eters in the LCD transducer block.
13 2013 NOW_DISPLAYING 0 AUTO Indicates the number that the input currently displayed on the
LCD occupies among valid inputs of information.
14 2014 DISP_TARGET_FORCE 0 AUTO A parameter for identifying information of valid inputs that you
want to view
0: Scroll knob is active
1: No.01 in valid connection
2: No.02 in valid connection
3: No.03 in valid connection
4: No.04 in valid connection
5: No.05 in valid connection
6: No.06 in valid connection
7: No.07 in valid connection
8: No.08 in valid connection
9: No.09 in valid connection
10: No.10 in valid connection
11: No.11 in valid connection
12: No.12 in valid connection
13: No.13 in valid connection
14: No.14 in valid connection
15: No.15 in valid connection
16: No.16 in valid connection
15 2015 NO_OF_VALID_CON 0 AUTO Indicates how many of the 16 inputs are valid. (Corresponds
to the denominator when DISP_PAGE_INFO is displayed.)
16 2016 VALID_CON_SUMMARY 0xFFFF AUTO Sets which of the 16 inputs are valid inputs.
17 2017 MAO_CON_SUMMARY 0x0000 AUTO Indicates which of the 16 inputs gets MAO block values.
18 2018 ISEL_CON_SUMMARY 0x0000 AUTO Indicates which of the 16 inputs gets IS block values.
19 2019 SIM_CON_SUMMARY 0xFFFF AUTO Indicates which of the 16 inputs gets Simulation state values.
20 2020 BAR_GRAPH_SELECT 0 AUTO Use to specify whether bar graphs should be displayed in the
lower field of the LCD. (16 input batch setting)
21 2021 EACH_BAR_GRAPH 0x0000 AUTO Use to specify whether bar graphs should be displayed in the
lower field of the LCD. (Each input batch setting)
22 2022 MAIN_TAG_SCROLL 1 AUTO Use to set the character scroll function for MAIN_TAG infor-
mation.
0 = scroll function Off
1 = scroll function On
23 2023 V_SCROLL_BAR 2 AUTO Use to turn the vertical scroll bar on and off.
0 = Scroll bar display function Off
1 = Scroll bar display function On
2 = On only during display switch
24 2024 SCROLL_DIRECTION 0 AUTO A parameter for changing scroll knob turning direction, page
number turning direction and turning direction of the vertical
scroll bar.
0 = Clockwise turn of scroll knob à Increases page numbers
0 = Counterclockwise turn of scroll knob à Increases page
numbers
