Item Description Code
Canadian Standards
Association (CSA) CSA explosion-proof Approval
Applicable Standard: C22.1-98, C22.2 No.0, C22.2 No.0.4, C22.2 No.0.5, C22.2 No.25,
C22.2 No.30, C22.2 No.94, C22.2 No.142, C22.2, No.61010-1,
ANSI/ISA-12.27.01
Type of Protection: explosion-proof for Class I, Groups B, C and D;
Class II, Groups E, F and G; Class III.
For Class I, Division 2 locations-
“FACTORY SEALED, CONDUIT SEAL NOT REQUIRED.”
Enclosure: Type 4X
Temperature Class: T6...T1 (Integral Type Vortex Flowmeter and Remote Type Vortex Flow Detector)
T6 (Remote Type Vortex Flow Converter)
Ambient Temperature: –29 to +60°C (Integral Type Vortex Flowmeter and Remote Type Vortex Flow
Detector)
–40 to +60°C (Remote Type Vortex Flow Converter)
Process Temperature : T6;85°C, T5;100°C, T4;135°C, T3;200°C, T2;300°C, T1;450°C
Enclosure : Type 4X
Coating of Enclosure: Epoxy resin coating or Polyurethane resin coating.
Electrical Connection: ANSI 1/2NPT female (Special)
CF1
Process Sealing Certifi cation
Dual Seal Certifi ed by CSA to the requirement of ANSI/ISA 12.27.01
No additional sealing required
CF11
IECEx IECEx Flameproof Approval
Applicable Standard: IEC60079-0, IEC60079-1
Type of Protection:
Ex d IIC T6...T1 Gb (Integral Type Vortex Flowmeter and Remote Type Vortex Flow Detector)
Ex d IIC T6 Gb (Remote Type Vortex Flow Converter)
Temperature Class : T6...T1 (Integral Type Vortex Flowmeter and Remote Type Vortex Flow Detector)
T6 (Remote Type Vortex Flow Converter)
Process Temperature : T6 (–40 to 80°C), T5 (–40 to 100°C), T4 (–40 to 135°C),
T3 (–40 to 200°C), T2 (–40 to 300°C), T1 (–40 to 450°C)
(Use /HT version above 250°C)
Ambient Temperature: –29 to 60°C (Integral Type Vortex Flowmeter and Remote Type Vortex Flow
Detector)
–40 to 60°C (Remote Type Vortex Flow Converter without indicator)
–30 to 60°C (Remote Type Vortex Flow Converter with indicator)
Ambient Humidity: 0 to 100%RH (No condensation)
Electrical Connection: ANSI 1/2NPT female, ISO M20 × 1.5 female
SF2
Technology
Institution of
Industrial Safety
(TIIS), Japan TIIS explosion-proof Ex d IIC T6 approval
Ambient Temperature: –20 to 60°C (Integral Type Vortex Flowmeter and Remote Type Vortex Flow
Detector)
Electrical connection: JIS G1/2 female
JF3
Item AI1 for Flow Rate Signal (Standard)
AI2 for Temperature Signal
(with MV Option)
Tag number (PD_TAG) Set to “FT1003” by default unless otherwise specifi ed when ordered.
Output mode (L_TYPE) “Direct”
Upper and lower calculation range limits
and unit (XD_SCALE) The upper range limit will be set to the
maximum fl ow rate range specifi ed in the
registered sizing data, or to the 0 to 10 m
3 /h
range in case of UNCALIBRATION.
–40 to +260°C or –40 to +482°F
Upper and lower output range limits and
unit (OUT_SCALE) _
Node address
Set to 0xF2 unless otherwise specifi ed when ordered.
Explanation of parameters:
(1) XD_SCALE: Defi nes the input values from the transducer block (input range of the sensor) corresponding
to 0% and 100% values in the calculation inside the AI function block. For a digitalYEWFLO,
the values set as the fl ow span or temperature range (option) are stored in this parameter.
(2) OUT_SCALE: Output scaling parameter. Defi nes the output values corresponding to 0% and 100% values
in the calculation inside the AI function block.
(3) L_TYPE: Determines whether the values passed from the transducer block (sensor) should be
output without processing (“Direct”) or through scaling conversion based on OUT_SCALE
(“Indirect”).
