(4) AI2 Function Block
Menus
Block Info
|
Block Tag
|
Tag Description
|
|
Strategy
Alert Key
Block Mode
|
Target
|
Actual
|
Permitted
|
Normal
Dynamic Variables
|
Field Value
|
|
Status
|
|
Value
|
Process Value
|
|
Status
|
|
Value
|
Output
|
Status
|
Value
Configuration
|
Block Mode
|
|
Target
|
|
Actual
|
|
Permitted
|
|
Normal
|
Channel
|
Transducer Scale
|
|
EU at 100%
|
|
EU at 0%
|
|
Units Index
|
|
Decimal
|
Output Scale
|
|
EU at 100%
|
|
EU at 0%
|
|
Units Index
|
|
Decimal
|
Process Value Filter Time
|
Options
|
Linearization Type
|
Low Cutoff
|
I/O Options
|
Status Options
Diagnostics/Alerts
|
Block Error
|
|
|
Alert Parameters
|
Block Almarm
|
|
Unacknowledged
|
|
Alarm State
|
|
Time Stamp
|
|
Subcode
|
|
Value
|
Alarm Summary
|
|
Current
|
|
Unacknowledged
|
|
Unreported
|
|
Disabled
|
Acknowledge Option
|
Alarm Hysteresis
|
High High Alarm Set
|
|
High High Priority
|
|
High High Limit
|
|
High High Alarm
|
|
|
Unacknowledged
|
|
|
Alarm State
|
|
|
Time Stamp
|
|
|
Subcode
|
|
|
Float Value
|
High Alarm Set
|
|
High Priority
|
|
High Limit
|
|
High Alarm
|
|
|
Unacknowledged
|
|
|
Alarm State
|
|
|
Time Stamp
|
|
|
Subcode
|
|
|
Float Value
|
Low Alarm Set
|
|
|
Low Priorit
|
Low Limit
|
|
Low Alarm
|
|
|
Unacknowledged
|
|
|
Alarm State
|
|
|
Time Stamp
|
|
|
Subcode
|
|
|
Float Value
|
Low Low Alarm Set
|
|
|
Low Low Priorit
|
Low Low Limit
|
|
Low Low Alarm
|
|
|
Unacknowledged
|
|
|
Alarm State
|
|
|
Time Stamp
|
|
|
Subcode
|
|
|
Float Value
|
Update Event
|
Unacknowledged
|
Update State
|
Time Stamp
|
Static Rev
|
Index
Others
|
|
|
Grant Deny
|
Grant
|
Deny
Query Device
AI Standard parameters
Simulation Enable
Simulation Disable
FA0904.ai
Note: Parameter name may differ according to a tool or host.
