Programming NetMaster
210140 90 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
46. Control Configuration Data #1
“+046”
This option allows the owner to turn ON or turn OFF
preprogrammed capabilities within NetMaster.
How to Program the Control Configuration
Data #1
1. Control must be in Manual Mode. Refer to
Entering the Manual Mode.
2. Press the DELICATES (+) or the COLD (-)
keypad until “PrOg” appears in the VFD. Press
the START (enter) keypad and “+001” will
appear in the VFD.
Figure 168
3. Press the DELICATES (+) or the COLD (-)
keypad to scroll through the programmable
options until “+046” appears in the VFD. Refer
to Figure 169.
Figure 169
4. When “+046” appears in the VFD, press the
START (enter) keypad. A number will appear in
the VFD. This number corresponds to the current
Control Configuration Data #1 Value.
5. Press the DELICATES (+) or the COLD (-)
keypad to increase or decrease the current
number to the desired number selected from
Table 5. Refer to Figure 170.
Figure 170
6. Press the START (enter) keypad when the
correct number appears in the VFD. The next
option, “+047”, will appear in the VFD.
NOTE: To program “+047” (Control Configuration
Data #3), refer to option 47. To program other
options, refer to the appropriate section.
How to Exit Programming Feature
1. Be sure the control shows a programmable option,
not a value.
2. While pressing and holding the NORMAL
keypad with one hand, press the PERM PRESS
keypad with the other hand. The control will
revert back to the ready mode. Refer to Figure 2.
C762I
C807I
C860I
1 Press this pad (+) to scroll forward or increase a value
2 Press this pad (enter) to choose a selected value or
option
3 Press this pad (-) to scroll back or decrease a value
1
3 2
