Programming NetMaster
105 210140 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
54. Error Code Programming
Parameter “+054”
This option allows the owner to turn on or turn off
certain errors in the control.
How to Program Error Code Programming
Parameter
1. Control must be in Manual Mode. Refer to
Entering the Manual Mode.
2. Press the DELICATES (+) or the COLD (-)
keypad until “PrOg” appears in the VFD. Press
the START (enter) keypad and “+001” will
appear in the VFD.
Figure 196
3. Press the DELICATES (+) or the COLD (-)
keypad to scroll through the programmable
options until “+054” appears in the VFD. Refer
to Figure 197.
Figure 197
4. When “+054” appears in the VFD, press the
START (enter) keypad. A number will appear in
the VFD. This number corresponds to the current
Error Code Programming Parameter Value.
5. Locate the desired number in the first column of
Table 9 on the following page.
6. Press the DELICATES (+) or the COLD (-)
keypad to increase or decrease the current
number until correct. Refer to Figure 198.
Figure 198
7. Press the START (enter) keypad when the
correct number appears in the VFD. The next
option, “+055”, will appear in the VFD.
NOTE: To program “+055” (Start Pulse Mode),
refer to option 55. To program other options, refer
to the appropriate section.
How to Exit Programming Feature
1. Be sure the control shows a programmable option,
not a value.
2. While pressing and holding the NORMAL
keypad with one hand, press the PERM PRESS
keypad with the other hand. The control will
revert back to the ready mode. Refer to Figure 2.
C762I
C815I
C815I
C860I
1 Press this pad (+) to scroll forward or increase a value
2 Press this pad (enter) to choose a selected value or
option
3 Press this pad (-) to scroll back or decrease a value
1
3 2
