PM-LX2-800 User Manual

Page 95

Subtractive Speed

Set the Memory Speed to Subtractive Speed

Decode Memory Address x [Varying defaults]

Use the Decode Memory Address option to manually enter the memory address that

should be used by this memory space. The defaults for the different memory spaces are

shown below

Memory Space 0: D00

Memory Space 1: 000

Memory Space 2: 000

Memory Space 3: 000

Decode Memory Size x [Varying defaults]

Use the Decode Memory Size option to manually enter the size of the memory space.

The defaults for the different memory spaces are shown below

Memory Space 0: 64 Bytes

Memory Space 1: 32 Bytes

Memory Space 2: 32 Bytes

Memory Space 3: 32 Bytes

5.4 PCI/PnP

Use the PCI/PnP menu (BIOS Menu 13) to configure advanced PCI and PnP settings.

WARNING!

Setting wrong values for the BIOS selections in the PCIPnP BIOS

menu may cause the system to malfunction.
