BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Advanced Chipset Settings
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
WARNING: Setting wrong values in below section
may cause system to malfunction.
> Video Configuration
Select Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 21: Chipset
5.7.1 Video Configuration
Use the Video Configuration menu (BIOS Menu 22) to set the configuration settings for
the flat panel screen connected to the system.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Video Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Internal Graphics Memory
[ 32 MB]
Boot Display Type [Panel + CRT]
Flat Panel Configuration
Flat Panel Type
[Auto]
Flat Panel Resolution [800x600]
Flat Panel Data Bus Type [9-24 bits, 1 pixel]
Flat Panel Refresh Rate [60 Hz]
Horizontal Sync Polarity [Active low]
Vertical Sync Polarity [Active low]
Select internal graphics
memory size in MB unit.
Please use even number of
Mbytes only.
Select Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 22: Video Configuration
