PM-LX2-800 User Manual
Page 59
4.7 Chassis Installation
WARNING:
Airflow is critical to the cooling of the CPU and other onboard components. The
chassis in which the PM-LX2-800 must have air vents to allow cool air to move
into the system and hot air to move out.
The PM-LX2-800 must be installed in a chassis with ventilation holes on the sides allowing
air to flow through the heat sink surface. In a system with an individual power supply unit,
the power supply cooling fan can also help generate airflow through the board surface.
NOTE:
IEI has a wide range of backplanes available. Please contact your vendor,
reseller or an IEI sales representative at [email protected] or visit the IEI website
(http://www.ieiworld.com.tw) to find out more about the available chassis.
4.8 Internal Peripheral Device Connections
The cables listed in Table 4-3 are shipped with the PM-LX2-800.
Quantity Type
1 ATA/33 flat cable
1 Single RS-232 cable w/o bracket
1 KB/MS PS/2 Y-cable
1 Dual USB cable w/o bracket
1 LAN cable
1 Power cable
1 VGA cable
Table 4-3: IEI Provided Cables
