6 floppy disk connector, Table 3-6: compactflash® connector pinouts – IEI Integration PM-LX2-800 User Manual

Page 34

background image

PM-LX2-800 User Manual

Page 34

6

DATA 7

31

DATA 15

7 HDC_CS0#

32

HDC_CS1

8 N/C

33

N/C

9 GROUND 34

IOR#

10 N/C

35 IOW#

11 N/C

36 N/C

12 N/C

37 INTERRUPT

13 VCC_COM 38 VCC_COM

14 N/C

39 CSEL

15 N/C

40 N/C

16 N/C

41 HDD_RESET

17 N/C

42 IORDY

18 SA2

43 N/C

19 SA1

44 VCC_COM

20 SA0

45 HDD_ACTIVE#

21 DATA

0 46 N/C

22 DATA

1 47 DATA

8

23 DATA

2 48 DATA

9

24 N/C

49 DATA

10

25 VCC-IN

CHECK2

50 GROUND

Table 3-6: CompactFlash® Connector Pinouts

3.2.6 Floppy Disk Connector

CN Label:

CN10 (solder side)

CN Type:

26-pin header

CN Location:

See Figure 3-8

CN Pinouts:

See Table 3-7

The floppy disk connector (CN10) is connected to a floppy disk drive.
