The Horizontal Sync Polarity option can only be configured if the Flat Panel Type option
is not set to Auto. Use the Horizontal Sync Polarity option to set the polarity of the
HSYNC signal to the panel. The Horizontal Sync Polarity options are:
Active High
Active Low (Default)
Vertical Sync Polarity [Low]
The Vertical Sync Polarity option can only be configured if the Flat Panel Type option is
not set to Auto. Use the Vertical Sync Polarity option to set the polarity of the VSYNC
signal to the panel. The Vertical Sync Polarity options are:
Active High
Active Low (Default)
5.8 Exit
Use the Exit menu (BIOS Menu 23) to load default BIOS values, optimal failsafe values
and to save configuration changes.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Exit Options
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Save Changes and Exit
Discard Changes and Exit
Discard Changes
Load Optimal Defaults
Load Failsafe Defaults
Exit system setup after
saving the changes.
F10 key can be used for
this operation
Select Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 23:Exit
