Connector Type Label
LAN connector 10-pin box header LAN
LED/Reset button connector 6-pin header CN6
Parallel Port connector 26-pin box header LPT1
PC/104 connector PC/104 connector CN8
RS-232 Serial port1 connector 10-pin box header COM1
RS-232 Serial port2 connector 10-pin box header COM2
RS-422/485 Serial port3 connector 4-pin wafer connector CN7
TTL LCD connector 40-pin crimp connector CN5
USB connector 8-pin header USB1
VGA connector 10-pin box header VGA1
Table 3-1: Peripheral Interface Connectors
3.2 Internal Peripheral Connectors
Internal peripheral connectors on the motherboard are only accessible when the
motherboard is outside of the chassis. This section has complete descriptions of all the
internal, peripheral connectors on the PM-LX2-800 motherboard.
3.2.1 12V / 5V Power Connector
CN Label: CN3
CN Type: 3-pin terminal block
CN Location: See Figure 3-3
CN Pinouts: See Table 3-2
The 12V / 5V Power Connector supplies power to the motherboard.
