PM-LX2-800 User Manual
Page 92
Auto Legacy USB support disabled if no USB devices are
connected
5.3.8 IT8888 ISA Decode IO Spaces
Access the IT8888 ISA Decode Spaces configuration settings (BIOS Menu 11) in the
Integrated Peripherals menu and make the appropriate I/O space settings.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
ISA Decode I/O Spaces
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Decode I/O Space 0
[Disabled]
I/O Decoding Speed [Slow Speed]
I/O Decoding Base Addr. [100]
I/O Decoding Size [128 Bytes]
Decode I/O Space 1 [Disabled]
I/O Decoding Speed [Slow Speed]
I/O Decoding Base Addr. [180]
I/O Decoding Size [ 64 Bytes]
Decode I/O Space 2 [Disabled]
I/O Decoding Speed [Slow Speed]
I/O Decoding Base Addr. [1C0]
I/O Decoding Size [ 32 Bytes]
Decode I/O Space 3 [Disabled]
I/O Decoding Speed [Slow Speed]
I/O Decoding Base Addr. [200]
I/O Decoding Size [128 Bytes]
Positively Decode I/O
Space Window 0.
Select Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 11: IT8888 ISA Decode IO
Decode IO Space x [Disabled]
Use the Decode IO Space x option to enable or disable the decoding of a particular IO
space.
Disabled (Default) IO space decoding is disabled
Enabled IO space decoding is enabled and the options below are
accessible
