NANO-LX CPU Card
91
WARNING!
When installing electronic components onto the embedded module or
installing the embedded module onto the baseboard, always take anti-static
precautions in order to prevent ESD damage to the motherboard and other
electronic components like the CPU and DIMM modules
The following components must be installed onto the motherboard or connected to the
motherboard during the installation process.
NOTE:
The NANO-LX embedded module already has a preinstalled AMD CPU.
SO-DIMM module
Mount the embedded module onto a baseboard
4.3.1 DIMM Module Installation
4.3.1.1 Purchasing the Memory Module
When purchasing SO-DIMM modules, the following considerations should be taken into
account:
The maximum SO-DIMM capacity supported is 1GB
The maximum SO-DIMM frequency supported is 400MHz.
The SO-DIMM chip must be a 200-pin memory chip
4.3.1.2 SO-DIMM Module Installation
The NANO-LX embedded module has one 200-pin SO-DIMM socket. To install the
SO-DIMM module, follow the instructions below.
Turn the NANO-LX over so that the SO-DIMM socket is facing up. Step 1:
