68

IEI

®

Technology, Corp.

PIN

DESCRIPTION

PIN

DESCRIPTION

1 GND

2 GND

3 +12V

4 +12V

Table 3-23: CN2 Connector Pinouts

Figure 3-21: CN2 Connector Location

3.2.20 Power Input Connector

CN Label:

CN25

CN Type:

3-pin header

CN Pinouts:

See Table 3-24

CN Location:

See Figure 3-22
