Connector Type Label
FDD connector 26-pin header CN34
IDE Interface connector 44-pin header CN13
Inverter connector 5-pin header CN26
IrDA connector 5-pin header CN32
Keyboard/Mouse connector 6-pin header CN30
LED Power connector 6-pin header CN12
LVDS LCD Panel connector 20-pin header CN23
Parallel Port connector 26-pin header CN20
PC/104-Plus connector PC/104-Plus connector CN7
Power connector (Default) 4-pin header CN2
Power connector (Optional) 2-pin header CN1
Power Input connector 3-pin header CN25
Reset Button connector 2-pin header CN6
SATA Drive port (150MB/s) SATA disk drive port CN10
SATA Drive port (150MB/s) SATA disk drive port CN11
Serial Communications connector 10-pin header CN14
Serial Communications connector 10-pin header CN15
Serial Communications connector 10-pin header CN16
Serial Communications connector 10-pin header CN17
Serial Communications connector 14-pin header CN19
TFT TTL LCD 40-pin header CN22
Table 3-1: Peripheral Interface Connectors
