NANO-LX CPU Card
39
3.1.3 Rear Panel Connectors
Table 3-2 lists the rear panel connectors on the NANO-LX CPU card. Detailed descriptions
of these connectors can be found in Section 4.6.
Connector Type Label
Serial connector RS232 connector CN21
VGA Connector 15-pin VGA connector CN24
Ethernet connector RJ-45 CN27
USB Combo connector USB Port CN28
USB Combo connector USB Port CN29
Keyboard/Mouse connector PS/2 CN31
Table 3-2: Rear Panel Connectors
3.1.4 Onboard Jumpers
Table 3-3 lists the onboard jumpers. Detailed descriptions of these jumpers can be found in
Section 3.4.
Connector Type Label
AT/ATX Power Mode Select 2-pin header JP4
COM1, COM2 RI Pin and Voltage Selection
(Optional)
10-pin header JP2
COM3 RS422/RS485 Select 3-pin header JP3
LCD Panel (LVDS/TTL) Voltage select 2-pin header JP7
LCD PANEL SHIFT CLOCK 3-pin header JP1
PC104 Plus VIO Voltage Select 3-pin header JP5
SERIRQ Select 2-pin header JP6
Table 3-3: Onboard Jumpers
3.2 Internal Peripheral Connectors
Internal peripheral connectors on the CPU card are only accessible when the CPU card is
outside of the chassis. This section has complete descriptions of all the internal, peripheral
connectors on the NANO-LX CPU card.
