NANO-LX CPU Card
79
3.3.4 USB Combo Connectors
CN Label: CN28, CN29
CN Type: USB port
CN Pinouts: See Table 3-34
CN Location: See Figure 3-27
The USB comb connector provides the connectivity to additional USB devices through an
adapter cable. Various adapters may come with USB ports on a slot bracket or ports that
can be attached to D-SUB openings on a chassis. USB devices connect directly to the
USB connectors on the rear panel.
PIN DESCRIPTION PIN DESCRIPTION
1 +5V 8 GND
2 USBDT2N 7 USBDT3P
3 USBDT2P 6 USBDT3N
4 GND 5 +5V
Table 3-34: CN28, CN29 Connector Pinouts
3.3.5 Keyboard/Mouse Connector
CN Label: CN31
CN Type: PS/2
CN Pinouts: See Table 3-35 and Figure 3-31
CN Location: See Figure 3-27
The Keyboard/Mouse connector connects to a mouse and keyboard.
