IEI

Technology, Corp.

2.15 Power

Consumption

Table 2-2 shows the power consumption parameters for the NANO-LX when an AMD

LX-800 CPU is running with a 400MHz, 256MB DDR RAM module.

Voltage

Current

+12V

0.92A

Table 2-2: Power Consumption

2.16 PXE: Pre-Boot Execution Environment

PXE is an open industry standard developed by a number of software and hardware

vendors. IEI BIOS PXE feature allows a workstation to boot from a server on a network by

receiving a pre-OS agent prior to booting the operating system on the local hard drive.

Figure 2-2: PXE: Pre-Boot Execution Environment
