IEM-9452 ETX Module
Page 42
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GROUND 24 SDVOC_RED
2 SDVOC_CLK# 25 GROUND
3 SDVOC_CLK 26 SDVOB_BLUE#
4 GROUND 27 SDVOB_BLUE
5 SDVOC_GREEN# 28 GROUND
6 SDVOC_GREEN 29 SDVOB_RED#
7 GROUND 30 SDVOB_RED
8 SDVOB_CLK# 31 GROUND
9 SDVOB_ CLK 32 SDVO_FLDSTALL#
10 GROUND 33 SDVO_FLDSTALL
11 SDVOB_GREEN# 34 GROUND
12 SDVOB_GREEN 35 SDVO_TVCLKIN#
13 GROUND 36 SDVO_TVCLKIN
14 SDVOC_INT# 37 GROUND
15 SDVOC_INT 38 SDVO_CLK
16 GROUND 39 SDVO_DATA
17 SDVOB_INT# 40 PCIRST#1
18 SDVOB_INT 41 VCC5
19 GROUND 42 VCC5
20 SDVOC_BLUE# 43 VCC5
21 SDVOC_BLUE 44 NC
22 GROUND 45 NC
23 SDVOC_RED#
Table 4-7: SDVO Connector Pinouts
