IEM-9452 ETX Module

Page 41

4 GND

5 RX-

6 RX+

7 GND

Table 4-6: SATA Drive Connector Pinouts

4.2.6 SDVO Connector

CN Label:

CN3

CN Type:

45-pin crimp (1x45)

CN Location:

See Figure 4-7

CN Pinouts:

See Table 4-7

The 45-pin SDVO (Serial Digital Video Out) connector supports additional video signaling

interfaces.

Figure 4-7: SDVO Connector Pinout Locations
