IEM-9452 ETX Module
Page 5
1.2.1 IEM-9452 Connectors
The IEM-9452 has the following interface connectors on-board:
1 x ETX-X1 connector (reverse side)
1 x ETX-X2 connector (reverse side)
1 x ETX-X3 connector (reverse side)
1 x ETX-X4 connector (reverse side)
1 x SATA connector (front side)
1 x SO-DIMM socket (front side)
1.2.2 IEM-9452 IO Interface Support
The IEM-9452 embedded module supports the following IO interfaces on the baseboard:
2 x RS-232
4 x USB 2.0
1 x LPT/FDD
1 x KB/MS
1 x IDE
1 x IR
1 x CF Type II
1.2.3 Technical Specifications
IEM-9452 technical specifications are listed in Table 1-2. Detailed descriptions of each
specification can be found in Chapter 2.
SPECIFICATION IEM-9452-L7400 IEM-9452-CM423
CPUs Supported 1.5 GHz Intel® Core™2 Duo
L7400 with a 667 MHz FSB
1.06 GHz Intel® Celeron® M
423 with a 533 MHz FSB
Cache Memory 4 MB L2 cache 1 MB L2 cache
System Chipset Intel® 945GME
I/O Controller ICH7-M
