4.1.2 Board-to-Board Interface Connectors
Table 4-1 shows a list of the board-to-board interface connectors on the IEM-9452.
Detailed descriptions of these connectors can be found below.
Connector Type Label
ETX-X1 connector 100-pin ETX connector X1
ETX-X2 connector 100-pin ETX connector X2
ETX-X3 connector 100-pin ETX connector X3
ETX-X4 connector 100-pin ETX connector X4
SATA connector 7-pin SATA connector CN1
SDVO connector 45-pin connector CN3
Table 4-1: Peripheral Interface Connectors
4.2 Board-to-Board Peripheral Connectors
Board-to-board connectors are found on the ETX module and are only accessible when
the ETX module is outside of the chassis. This section has complete descriptions of all the
internal, peripheral connectors on the IEM-9452.
4.2.1 ETX-X1 Connector
CN Label: X1
CN Type: 100-pin ETX connector
CN Location: See Figure 4-2
CN Pinouts: See Table 4-2
The standard ETX-X1 connector locations and pinouts are shown below.
