Introduction
10
CAUTION! START-UP KIT LIFETIME IS SEVEN (7) DAYS.
The designed operating lifetime for start-up kit components is seven (7) days
of continuous operation. If a patient must be treated for a longer period, a new
start-up kit must be installed in the System. Failure to adhere to this time limit
may cause injury to the patient.
Data Memory
The System is capable of continuously recording patient temperature and system
activity for up to 21 days. This stored data can be downloaded to an attached
computer over a serial interface using optional software furnished by ZOLL.
Saline Circuit Diagram
A flow diagram is printed on the inside of the top cover. Use this diagram to
assure that the start-up kit has been installed correctly.
Figure 2-8. Flow Diagram.
