70 Agilent FrameScope 350 User’s Manual
3 Cable Testing with the FrameScope 350
Setting Up an Autotest
Checkmarks indicate fields that appear in the labels. Yellow tags
next to the categories indicate that automatic number
incrementing is enabled for that field.
To configure the hierarchical labeling format:
1 Press a category to check it for inclusion in the label, or to uncheck it
so it does not appear. When all the desired categories are checked,
press Next. The Site Setup screen changes to show the selected
categories.
2 If you want the numbers for any field to increase automatically with
each new label and test, press the category, then press Enable
Auto-Increment
so that a checkmark appears, as in the figure
above.
3 To set the beginning number for a field to other than 1, press the
category name, then press the Enter Start Value field. The onscreen
keyboard opens.
