Introducing the FrameScope 350 1
The Main Menu at a Glance
Agilent FrameScope 350 User’s Manual 9
Autotest Button Calls the Network Autotest Setup screen.
The Cable Tab
Figure 7 FrameScope Cable Tab (normal mode)
Tab Title Displays the name of the tab.
Certification Test Buttons Launch a certification autotest. For
example, Category 5E or Category 6 cable certification.
Setup Menu Button Opens the Setup menu.
Calibration Button Opens the Calibration screen for calibrating
the FrameScope 350 with the Dual Remote 350.
System Menu Button Opens the System menu.
Tab title
Certification test buttons
Setup menu button
Calibration button
System menu button
N O T E
The Cable tab will look different if Expert Mode is turned on.
