Operator’s Manual
922258-00 Rev A 57
Table 5, List of required Equipment
Description Minimum Requirements Test Equipment Examples
Wide Band Oscilloscope 500 MHz bandwidth 2 mV -
200mv scale factors
1 ns -
10 μs sweep speed 2%
vertical accuracy
50 Ω termination
Teledyne LeCroy LT374 series
oscilloscope
Digital Multimeter DC: 0.01% accuracy
AC: 0.2% accuracy to measure
200 mV and 2 V rms @ 1 kHz
6½ digit resolution HP 34401A
Fluke 8842A-09
Keithley 2001
Oscillator/Function Generator Sine Wave output 20 Vp-p at 70
Hz Stanford Research Model DS340
Hewlett Packard 33120A
Leader LAG-120B
Leveled Sine Wave Generator Relative output level accurate to
0.5 dB flatness from 1
– 100 MHz
and 50 kHz.
Output adjustable to 2 Vp-p
Tegam SG503 with TM series
mainframe and 012-0482-00 output
cable
Terminator, in-line, BNC 50 Ω ± 2% coaxial termination ITT Pomona 4119-50
AIM 27-9008
Terminator, precision, BNC 50 Ω ± 0.05% Teledyne LeCroy TERM-CF01
Attenuator, BNC 50 Ω ± 2%, ÷10 (20 dB) ITT Pomona 4108-20dB
AIM 279300-20
BNC coaxial cable, (3 ea) Male-male BNC, 50 Ω, 36” ITT Pomona 5697-36
BNC coaxial cable, (2 ea) Male-male BNC, 50 Ω, 4"-6" Pasternack Enterprises PE3067-5
BNC ’Y’ connector Male to dual female, BNC AIM 27-9294
BNC Tee connector Male to dual female, BNC AIM 27-8140
ITT Pomona 3285
BNC adapter Female to female AIM 25-7430
ITT Pomona 3283
Banana Plug adapter BNC female to dual banana plug ITT Pomona 1269
