- 51 -
Setting requirement
A: Required (function selection)
B: Required (network environment, etc.)
C: Checked (As a rule, the default value
on the parameter list must be used.)
Modbus/
TCP
IAI protocol
B/TCP
Transmission by
SEL program
No. Parameter name
Default value
(reference)
Input range Unit Remarks
B 158
IAI protocol B/TCP:
Port number of
connection destination
(AUTO mode)
64611 0~65535
* In the server mode “0” can be set.
0 = Ignore port number of connection destination
(Only the IP address is checked.)
* In the client mode “0” cannot be set.
C 159
IAI protocol B/TCP:
Own port number
(AUTO mode)
64516 1025~65535
* Important note: Be sure to set a unique number for each
own port number.
(The duplication of own port numbers is permitted only in
the IAI protocol B/TCP MANU/AUTO modes.)
[Other parameters]
Setting requirement
A: Required (function selection)
B: Required (network environment, etc.)
C: Checked (As a rule, the default value
on the parameter list must be used.)
Modbus/
TCP
IAI protocol
B/TCP
Transmission by
SEL program
No. Parameter name
Default value
(reference)
Input range Unit Remarks
C C C 6
PC/TP reconnection
delay time upon
software reset
11000 1~99999 msec
* Valid after the PC software/TP is closed and then
restarted.
